HDPE hopper liners UHMWPE liner plates
-
◆ Product name：
HDPE hopper liners UHMWPE liner plates
-
◆ Sort：
UHMWPE wear resistant liners
-
◆ Num：
SN1637197119
What is hdpe plastic liner / uhmwpe liner ?
The advantages are self-lubrication, wear resistance and Impact resistance of UHMWPE make it to be chosed by the chute liner, coal bunker liner, truck liner, mixing silo liner and other project whose convey or cohere easily when it been unloaded and delivered .
The UHMWPE liner is the best supporting facilities to protect the truck with the feature of non-stick, fast unloading, wear resistance and corrosion resistance. It is provide the fast and stable deliver of coal, cement, wheat, sugar and other powder and granular product. The UHMWPE truck liner / coal liner is can be made as your requirement . Any size, color and logo are available .
Property
Value
Density
0.94~0.98 g/cm³
Working temperature
-269~85℃
Melting temperature
130~160℃
Elongation break
350%
Tensile strength
45.3MPa
Rockwell hardness
R57
Bending strength
23MPa
Compressive strength
≥30 MPa
Impact strength
100~160KJ/m³
Charpy notched impact strength
≥140 KJ/m²
Ball indentation hardness
≥40 N/mm²
Heat conductivity
0.14~0.16%(m/m)
Water absorption
≤0.01%
Key properties of UHMWPE liner, coal bunker liner:
· No incrustatons of bulkmaterial
· No bridging caused in hoppers
· Enhanced protection of plan tand machinery against wear
· Faster bulk material flow
· Costo flining exist hopper with PE1000 is one third of the cost of mild steel
· PE-UHMW is half the weight of steel, despite being three times as thick
